Email this article Attic polychrome figured vessels from the state historical museum: comprehensive studies
- Authors: Zhuravlev D.V.1,2, Ilyina T.A.3, Tereschenko E.Y.2, Guryeva P.V.2, Kovalenko E.S.2, Kondratyev O.A.2, Kuzmina E.A.2, Kulikova E.S.2, Mandrykina A.V.2, Shaliavina N.B.2, Yatsishina E.B.2
-
Affiliations:
- State Historical Museum
- National Research Centre “Kurchatov Institute”
- Pushkin State Museum of Fine Arts
- Issue: Vol 69, No 6 (2024)
- Pages: 1062-1077
- Section: КРИСТАЛЛОГРАФИЧЕСКИЕ МЕТОДЫ В ГУМАНИТАРНЫХ НАУКАХ
- URL: https://rjmseer.com/0023-4761/article/view/673642
- DOI: https://doi.org/10.31857/S0023476124060172
- EDN: https://elibrary.ru/YGCKGE
- ID: 673642
Cite item
Open Access
Access granted
Full Text
Supplementary files
Supplementary Files
Action
1.
JATS XML
2.
Fig. 1. Photographs of objects: a – 1 (B 305/64) lekythos with a figurative image of a head in a diadem over a lush hairstyle, b – 2 (B 625/61) oinochoe in the form of a seated child teasing a rooster, c – 3 (B 625/1) vessel in the form of a seated boy with a dog.
Download (794KB)
3.
Fig. 2. Results of X-ray tomography of a lekythos with a figured image of a head: a, b – model of the arrangement of cavities and cracks in the walls of the object, cracks and places of gluing of fragments of the vessel are marked in red, cavities between loosely pressed parts of ceramics are marked in blue; c – model of the inner surface of the right side of the lekythos; g–e – tomographic sections: g – longitudinal, close to the central one, d – longitudinal, passing through the wings, e – transverse, passing through the center of the body; 1 – cavities between loosely pressed parts of ceramics, 2 – protrusions of material in the areas of overlapping parts of the structure, 3 – bending of material around the hole in the upper part of the body.
Download (638KB)
4.
Fig. 3. Results of X-ray tomography of an oinochoe in the form of a seated child teasing a rooster: a–c – model of the arrangement of cavities in the vessel walls; g – model of the inner surface of the front side; d – model of the inner surface of the back side; e – model of the inner surface of the left side; g – longitudinal tomographic section passing close to the center of the vessel; h – longitudinal tomographic section of the neck and handle; i – transverse tomographic section passing close to the center of the body; k – transverse tomographic section of the bottom; 1 – additional fragments of ceramic paste covering the side seams.
Download (659KB)
5.
Fig. 4. Results of X-ray tomography of a vessel in the form of a seated boy with a dog: a – model of the arrangement of cavities in the vessel walls; b – model of the inner surface of the front side; c – model of the inner surface of the back side; g – model of the inner surface of the bottom; d – arrangement of cavities inside the bottom material; e – longitudinal tomographic section passing through the bottom of the vessel; g–i – tomographic sections passing through the center of the body in three mutually perpendicular planes; 1 – cavities between loosely pressed parts of ceramics, 2 – ridges formed during the manufacture of the back side of the body, 3 – tourniquet of ceramic dough at the base of the pedestal.
Download (644KB)
6.
Fig. 5. X-ray fluorescence maps of the distribution of elements on the surface of the lekyth for three positions of the vessel relative to the X-ray beam.
Download (357KB)
7.
Fig. 6. RFLA maps of the distribution of elements on the surface of the oinochoe (sitting child with a rooster).
Download (443KB)
8.
Fig. 7. RFLA maps of the distribution of elements on the surface of a vessel in the form of a sitting boy with a dog.
Download (416KB)
9.
Fig. 8. Reconstruction of the painting of a lekythos with a figurative image of a female head in a diadem over a lush hairstyle (1); reconstruction of the painting of an oinochoe in the form of a seated child teasing a rooster (2); reconstruction of the painting of a vessel in the form of a seated boy with a dog, based on the surviving painting of analogues (3).
Download (770KB)
