Analysis of Crystalline Phases of Electroactive Forms of Copolymer Composite of Polyvinylidene Fluoride and Tetrafluoroethylene with Nanographite

Cover Page

Cite item

Full Text

Open Access Open Access
Restricted Access Access granted
Restricted Access Subscription or Fee Access

Abstract

The influence of the crystallization conditions of vinylidene fluoride (VDF) copolymer with tetrafluoroethylene (TFE) (F-42) from aprotic solvents dimethyl sulfoxide (DMSO) and dimethylformamide (DMF) under isothermal conditions at 60, 90, 150°C on the phase composition of the films was studied. The content of crystalline phases in F-42 films was studied using Fourier infrared spectroscopy, Raman spectroscopy, and X-ray phase analysis. The effect of filling copolymer films with nanographite on crystallinity phases was investigated. Filling with nanographite changes the crystal structure of polymer piezoelectric films and their piezoelectric properties, forming high-content electroactive β- and γ-phases during crystallization from 5 wt% solutions of aprotic solvents. Some features of the analysis of the content of crystalline allotropic phases by the above methods were found. The total content of crystalline electroactive phases of the VDF/TFE copolymer during isothermal crystallization from DMSO and DMF was 96–98%, while the content of the β-phase was 75–80%.

Full Text

Restricted Access

About the authors

V. I. Bachurin

Yaroslavl Branch of the Valiev Institute of Physics and Technology of the RAS

Author for correspondence.
Email: vibachurin@mail.ru
Russian Federation, Yaroslavl, 150067

N. G. Savinsky

Yaroslavl Branch of the Valiev Institute of Physics and Technology of the RAS

Email: vibachurin@mail.ru
Russian Federation, Yaroslavl, 150067

A. P. Khramov

Demidov Yaroslavl State University

Email: artem.khramov.99.99@mail.ru
Russian Federation, Yaroslavl, 150003

M. A. Smirnova

Yaroslavl Branch of the Valiev Institute of Physics and Technology of the RAS

Email: vibachurin@mail.ru
Russian Federation, Yaroslavl, 150067

R. V. Selyukov

Yaroslavl Branch of the Valiev Institute of Physics and Technology of the RAS

Email: vibachurin@mail.ru
Russian Federation, Yaroslavl, 150067

References

  1. Наумова О.В., Генералов В.М., Зайцева Э.Г., Латышев А.В., Асеев А.Л., Пьянков С.А., Сафатов А.С. // Микроэлектроника. 2021. Т. 50. С. 166. https://doi.org/10.31857/S0544126921030066
  2. Weinhold S., Litt M.H., Lando J.B. // Macromolecules. 1980. V. 13. P. 1178. https://doi.org/10.1063/1.327425
  3. Bužarovska A., Kubin M., Makreski P., Zanoni M., Gasperini L., Selleri G., GualandiС. // J. Polymer Res. 2022. V. 29. № 7. P. 272. https://doi.org/10.1007/s10965-022-03133-z
  4. Singh P., Borkar H., Singh B.P., Singh V.N., Kumar A. // AIP Adv. 2014. V. 4. № 8. P. 4. https://doi.org/10.1063/1.4892961
  5. Guo S., Duan X., Xie M., Aw K.C., Xue Q. // Micromachines. 2020. V. 11. P. 1076. https://doi.org/10.20944/preprints202011.0262.v1
  6. Liu Y., Aziguli H., Zhang B., Xu W., Lu W., Bernholc J., Wang, Q. // Nature. 2018. V. 562. № 7725. P. 96. https://doi.org/10.1038/s41586-018-0550-z
  7. Ramaiah N., Raja V., Ramu C. // Oriental J. Chem. 2021. V. 37. № 5. P. 1. https://doi.org/10.13005/ojc/370513
  8. Guo S., Duan X., Xie M., Aw K.C., Xue Q.G. // Micromachines. 2020. V. 11. P. 1076. https://doi.org/10.3390/mi11121076
  9. Davis G.T., McKinney J.E., Broadhurst M.G., Roth S. // J. Appl. Phys. 1978. V. 49. P. 4998. https://doi.org/10.1063/1.324446
  10. Grushevski E., Savelev D., Mazaletski L., Savinski N., Puhov D. // J. Phys. Conf. Ser. 2021. V. 2086. P. 012014. https://doi.org/10.1088/1742-6596/2086/1/012014
  11. Furukawa T. // Phase Transitions: A Multinational J. 1989. V. 18. P. 143. https://doi.org/10.1080/01411598908206863
  12. Живулин В.Е., Хайранов Р.Х., Злобина Н.А., Песин Л.А. // Поверхность. Рентген., синхротр. и нейтрон. исслед. 2020. № 11. С. 36. https://doi.org/10.31857/S1028096020110175
  13. Живулин В.Е., Евсюков С.Е., Чалов Д.А., Морилова В.М., Андрейчук В.П., Хайранов Р.Х., Маргамов И.Г., Песин Л.А. // Поверхность. Рентген., синхротр. и нейтрон. исслед. 2022. № 9. С. 3. https://doi.org/10.31857/S1028096022090217
  14. Тарасов А.В. Взаимодействие фторполимера (сополимера тетрафторэтилена и винилиденфторида) с переходными металлами (Ta, Nb, Ti, W, Mo, Re): Автореф. дис. … канд. хим. наук: 02.00.04. М.: ИОНХ, 2010. 119 с.
  15. Gregorio J.R., Cestari M. // J. Polymer Sci. B. 1994. V. 32. № 5. P. 859. https://doi.org/10.1002/polb.1994.0903205
  16. Benz M., Euler W.B. // J. Аppl. Рolymer. Sci. 2003. V. 89. P. 1093. https://doi.org/10.1002/app.12267
  17. Shaik H., Rachith S.N., Rudresh K.J., Sheik A.S., Raman K.H.T., Kondaiah P., Mohan G. // J. Polym. Res. 2017. V. 24. Р. 1. https://doi.org/10.1007/s10965-017-1191-x
  18. Li X., Wang Y., He1 T., Hu Q., Yang Y. // J. Mater. Sci.: Mater. Electronics. 2019. V. 30. Р. 20174. https://doi.org/10.1007/s10854-019-02400-y
  19. Li Y., Xu J.Z., Zhu L., Zhong G.J., Li Z.M. // J. Phys. Chem. B. 2012. V. 116. P. 14951. https://doi.org/10.1021/jp3087607
  20. Cai X., Lei T., Sun D., Lin L. // RSC Adv. 2017. V. 7. P. 15382. https://doi.org/10.1039/c7ra01267e
  21. Li X., Wang Y., He T., Hu Q., Yang Y. // J. Mater. Sci.: Mater. Electronics. 2019. V. 30. P. 20174. https://doi.org/0.1007/s10854-019-02400-y
  22. Chen C., Cai F., Zhu Y., Liao L., Qian J., Yuan F.G., Zhang N. // Smart Mater. Struct. 2019. V. 28. P. 065017. https://doi.org/10.1088/1361-665X/ab15b7
  23. Vasic N., Steinmetz J., Görke M., Sinapius M., Hühne C., Garnweitner G. // Polymers. 2021. V. 13. P. 3900. https://doi.org/10.3390/polym13223900
  24. BoccaccioT., BottinoA., CapannelliG., PiaggioP. // J. Membrane Sci. 2002. V. 210. P. 315. https://doi.org/10.1016/s0376-7388(02)00407-6
  25. Simoes R.D., Job A.E., Chinaglia D.L., Zucolotto V., Camargo‐Filho J.C., Alves N., Constantino C.J.L. // J. Raman Spectrosc. 2005. V. 36. P. 1118. https://doi.org/10.1002/jrs.1416
  26. Ueda A., Ali O., Zavalin A., Avanesyan S., Collins W.E. // Biosensors and Bioelectronics Open Access. 2018. V. 2018. P. BBOA-111. https://doi.org/10.29011/BBOA-111.100011
  27. Kobayashi M., Tashiro K., Tadokoro H. // Macromolecules. 1975. V. 8. P. 158. https://doi.org/10.1021/ma60044a013
  28. Miranda T., Riosbaasa V., Lohb K.J., O’Bryanc G., Loyola B.R. // Proc. SPIE. 2014. V. 9061. P. 235. https://doi.org/10.1117/12.2045430
  29. Chapron D., Rault F., Talbourdet A., Lemort G., Cochrane C., Bourson P., Devaux E., Campagne C. // J. Raman Spectrosc. 2021. https://doi.org/10.1002/jrs.6081. HAL Id: hal-03163716. https://hal.univ-lorraine.fr/hal-03163716
  30. Job A.E., Simoes R.D., J.A. Giacometti J.A., Zucolotto V., Oliveira O.N., Gozzi J.G., Chinaglia D.L., Constantino C.J.L. // Appl. Spectrosc. 2005. V. 59. P. 275. https://doi.org/10.1366/000370205358533
  31. Кочервинский В.В., Сульянов С.Н. // ФТТ. 2006. Т. 48. С. 1016. http://journals.ioffe.ru/articles/viewPDF/3441
  32. Кочервинский В.В., Малышкина И.А., Воробьев Д.В., Бессонова Н.П. // ФТТ. 2010. Т. 52. С. 1841. http://journals.ioffe.ru/articles/viewPDF/1979
  33. Кочервинский В.В. // Russ. Chem. Rev. 1996. V. 65. P. 865. https://doi.org/ 10.1070/RC1996v065n10ABEH000328
  34. Кочервинский В.В., Мурашева Е.М. // Высоком. соединения. А. 1991. Т. 33. № 10. С. 2096.
  35. Кочервинский В.В., Киселев Д.А., Малинкович М.Д., Павлов А.С., Козлова Н.В., Шмакова Н.А. // Высокомол. соединения. А. 2014. Т. 56. С. 53. https://doi.org/10.7868/S2308112014010064

Supplementary files

Supplementary Files
Action
1. JATS XML
Download
2. Fig. 1. FT-IR spectra of F-42 samples crystallised at 60°C from solution: DMSO/F-42 (1); DMSO/F-42 (2); DMSO/F-42-nanographite (3); DMSO/F-42-nanographite (4).

Download (167KB)
Indexing metadata
3. Fig. 2. CPC spectrum of F-42 powder.

Download (163KB)
Indexing metadata
4. Fig. 3. CPC spectrum of F-42 film crystallised from 5 wt% F-42 in DMSO with the addition of 5 wt% nanographite at 60°C for 72 h after the spectral response separation procedure.

Download (169KB)
Indexing metadata
5. Fig. 4. XRD spectrum of the underside of a sample film crystallised from 5 wt% F-42 filled with 5 wt% nanographite at 60 °C for 72 h from DMSO solution. Two D peaks (band around 1340 cm-1) and a G-band around 1570 cm-1 are observed in the spectrum.

Download (80KB)
Indexing metadata
6. Fig. 5. SEM image of the surface of the F-42 film sample filled with 5 wt% nanographite.

Download (347KB)
Indexing metadata
7. Fig. 6. Diffractogram of a sample of initial F-42 powder after the peak separation procedure.

Download (156KB)
